High Speed Centrifuge JTHF TGL-16XYJ-2

Capacity: 12×1.5ml, 12×0.2ml
Max Speed: 16,000 rpm (adjustable)

I. Overview

Centrifugal separation technology is a novel method based on the sedimentation behavior of particles under varying centrifugal forces. Particles differing in density, size, or shape settle at distinct rates, enabling the separation of heterogeneous mixtures. This centrifuge is designed for biochemical research and large-scale substance isolation, including:

• Cell collection & plasma separation

• DNA/protein extraction from purified samples

• Isolation of viruses, E. coli, cellular components, and nucleoprotein particles.

II. Technical Specifications

1. Power Supply: AC 220V, 50Hz

2. Motor Power: 150W

3. Speed Range: 1,000–16,000 rpm (adjustable)

4. Centrifugal Capacity: 12×1.5ml

5. Timer: 1–60 minutes or continuous operation

6. Relative Centrifugal Force (RCF): 17,000×g

Note: The capacity "120.2ml" in the original text might contain a formatting error. Based on context, it is likely intended to be "12×0.2ml". Please verify with the manufacturer for accuracy.
