Biological Microscope QS BX-102B
The BX-101B features a 160mm Limited Teleoptics system, paired with 195-series achromatic objectives (4×, 10×, 40×s, 100×s oil) and a 10× (18mm field) eyepiece.
Its 45° tilted, 360° swiveling monocular head caters to single-user workflows, while the 4-hole outward converter, Abbey condenser (NA1.25), and 3W built-in LED lighting ensure reliable imaging.
With a 146×135mm dual platform (76×51mm travel) and coaxial focusing (0.0018mm fine adjustment), it’s ideal for basic lab or educational use—compact at 30×20×38cm.
Category | Specific Configuration | BX-101B | BX-102B | BX-102C |
|---|---|---|---|---|
Optical System | Limited Teleoptics 160mm | ● | ● | ● |
Viewing Head | Monocular viewing head, 45° tilt, 360° swivel | ● | ||
viewing head | Hinged binocular head, 30 degree tilt, pupil distance48mm-75mm | ● | ||
viewing head | Hinged trinocular head, 30 degree tilt, pupil distance48mm-75mm | ● | ||
goggles | Large Field Eyepiece WF10X/18mm | ● | ● | ● |
goggles | Large Field Eyepiece WF16X/13mm | character used in Taiwan asa substitute for a real name | character used in Taiwan asa substitute for a real name | character used in Taiwan asa substitute for a real name |
objective (optics) | Finite Distance 195 Series Achromatic Objective Lenses 4X10X 40Xs 100Xs(oil) | ● | ● | character used in Taiwan asa substitute for a real name |
objective(optics) | Limited Distance 195 Series High Contrast Flat FieldObjective 4X 10x 40Xs 100Xs (oil) | character used in Taiwan asa substitute for a real name | character used in Taiwan asa substitute for a real name | ● |
resolver | Outward facing 4-hole converter | ● | ● | ● |
spotting scope | Abbey spotting scope NA1.25 with variable light bar | ● | ● | ● |
focusing system | Coaxial coarse and fine adjustment mechanism, fineadjustment grid value 0.0018mm, coarse travel 36mm perrevolution | ● | ● | ● |
litter-bearing platform | Dual mobile platform Dimensions 146x135mm, range ofmovement 76mmx51mm | ● | ● | ● |
illumination | Built-in lighting system 3W/LED lighting | ● | ● | ● |
illumination | 6V 20W halogen lamp, brightness adjustable | character used in Taiwan asa substitute for a real name | character used in Taiwan asa substitute for a real name | character used in Taiwan asa substitute for a real name |
Product unit size | 30x20x38cm | ● | ● | ● |
Specification
BX-101B | BX-102B | BX-102C | ||
optical system | Limited Teleoptics 160mm | ● | ● | ● |
viewing head | Monocular viewing head, 45° tilt, 360° swivel | ● | ||
Hinged binocular head, 30 degree tilt, pupil distance 48mm-75mm | ● | |||
Hinged trinocular head, 30 degree tilt, pupil distance 48mm-75mm | ● | |||
goggles | Large Field Eyepiece WF10X/18mm | ● | ● | ● |
Large Field Eyepiece WF16X/13mm | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | |
objective (optics) | Finite Distance 195 Series Achromatic Objective Lenses 4X 10X 40Xs 100Xs (oil) | ● | ● | character used in Taiwan as a substitute for a real name |
Limited Distance 195 Series High Contrast Flat Field Objective 4X 10X 40Xs 100Xs (oil) | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | ● | |
resolver | Outward-facing four-hole converter | ● | ● | ● |
Outward facing 5-hole converter | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | |
spotting scope | Abbey spotting scope NA1.25 with variable light bar | ● | ● | ● |
focusing system | Coaxial coarse and fine adjustment mechanism, fine adjustment grid value 0.0018mm, coarse travel 36mm per revolution | ● | ● | ● |
litter-bearing platform | Dual mobile platform Dimensions 146x135mm, range of movement 76mmx51mm | ● | ● | ● |
illumination | Built-in lighting system 3W/LED lighting | ● | ● | ● |
6V 20W halogen lamp, brightness adjustable | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | character used in Taiwan as a substitute for a real name | |
Product unit size | 30x20x38cm | ● | ● | ● |
