Portable X-ray System HY P-602VET

Lightweight, flexible-use design. 0.106msv low radiation. S1/S2 adult sizes with 16-bit grayscale & multi-format imaging.
High-frequency inverter boosts clarity. 65,536 gray levels. S1 (20×30mm) / S2 (25×30mm) imaging areas for adults.
60KV tube voltage, 2mA current. 0.8mm focal spot. ≤0.25mGy/h leakage. Safe, precise for adult patients.

Categories: Vet X-Ray Machine, Veterinary Equipment Tags: Machine with X Ray, Portable X-ray System, Portable Xray DR System

Description
Reviews (0)

Description

High frequency inverter technology, higher imaging effect.
The design is lightweight and easy to operate, especially suitable for scenarios that require flexible use
The radiation dose is 0.106msv, which meets international standards.
Size 1 is mainly for adult patients. It consists of a control box, a USB port, and a receptor that is connected together by cables.

Size 1.5 is mainly for adult patients. It consists of a control box, a USB port, and a receptor that is connected together by cables.

Technical specification

Specifications	S1 (Size 1)	S2 (Size 1.5)
Grayscale	65,536 gray level(16 bit)	65,536 gray level(16 bit)
Imaging Area	*2030 mm²**	*2530 mm²**
Sensor Area	*2638 mm²**	*3138 mm²**
Thickness	5 mm	5 mm
Image Format	BMP/DIR/DCM/ JPEG/PNG/TIFF	BMP/DIR/DCM/ JPEG/PNG/TIFF

Technical features

Parameter	Value	Parameter	Value
Tube voltage	60KV	Battery Charger	950mAh
Tube current	2mA	Charging Time	DC 25.2V
Constant Output	0.01 – 2s	Weight	1.9kg
Focal spot	0.8mm	Frequency	70KHZ
SID SCALE	19°	Line Power	1:30
X-ray tube model	XD10D – 0.5/70	Leakage radiation	≤0.25mGy/h
