Intelligent Versatile

Max Power: 350W

• Excellent compatibility
• Available in vessel sealing
• Suitable for general surgery, vascular surgery, hepatobiliary and pancreatic surgery, cardiothoracic surgery, gastroenterology, TURP and TUVP
• Compatible with agron coagulation, cystoscopy, arthroscopy, laparoscopy and hysteroscopy

Technical parameters

1. Operating ambient temperature: 5℃ ~ 40℃
2. Relative humidity range: ≤80%
3. Atmosphere pressure range: 86.0 ~ 106.0 Kpa
4. Working modes:


   a. Pure cut: 1w ~ 350w (Load 500Ω)

   b. Blend 1: 1w ~ 250w (Load 500Ω)

   c. Blend 2: 1w ~ 150w (Load 500Ω)

   d. Coagulation 1 (Spray coag): 1w ~ 120w (Load: 500Ω)

   e. Coagulation 2 (Forced coag): 1w ~ 100w (Load: 500Ω)

   f. Coagulation 3 (Soft coag): 1w ~ 50 w (Load: 500Ω)

   g. Bipolar 1 (Vessel sealing): 1w ~ 150w (Load: 100Ω)

   h. Bipolar 2 (Micro bipolar): 1w ~ 100w (Load: 100Ω)

5. Technology data:


   a. Power supply: 220V/110V, 50Hz/60Hz

   b. Operating frequency: 417KHz

   c. Leakage currents to ground: Less than 0.5mA

   d. Leakage currents to patient: Less than 0.01mA

6. Accompanying accessories: Disposable electrosurgical pencil, Pad, Reusable bipolar forceps, Footswitch, Cable
7. Transport data:
