1. Double - person binocular at 90° to each other with monocular teaching mirror. Main mirror, auxiliary mirror and monocular teaching mirror share the same optical path, magnification, field of view and continuous stepless zoom.

2. The main mirror is an optical hinge surgical tube with a top - down viewing range of - 30° - 60° and 100% brightness.

3. Eyepiece: 12.5X Erfle wide - angle eyepiece. The main mirror uses high - resolution and high - definition optical hinge with strong three - dimensional sense and large depth of field.

4. Magnification: 5X - 25X electric continuous zoom

5. Field of view: 85mm - 8.5mm

6. Working distance: 200mm, 250mm, 300mm, 350mm, 400mm

7. Interpupillary distance adjustment: 54mm - 75mm

8. Diopter adjustment: ±5D

9. Electric fine focusing range: 40mm, focusing speed: 1 - 2mm/s

10. The microscope adopts X - Y two - dimensional rotating head structure with six - degree - of - freedom electric adjustment. The front - back, left - right and pitch ranges are all > 100°.

11. 15V150W cold light source coaxial illumination, surgical surface illuminance ≥80000LX. Xenon lamp illumination is optional, with illuminance up to 120,000LX, and daylight effect, larger depth of field.

12. Illumination range Ф70mm, spot size adjustable

Frame

1. Spring balanced type

2. Coarse adjustment range: 450mm

3. Maximum extension length of horizontal arm: 1200mm

4. Carrying arm rotation range: 240°

5. Power supply: 220V/50HZ, maximum power consumption: 200W
