Horizontal Steam Sterilizer DG WY Series
-
Features horizontal circular inner chamber + jacket structure, disc – embedded gear & electric lock door, pneumatic seals. Equipped with verification interface, optimized SUS304 pipeline (clamp – type).
-
HMI (touch + microcomputer) control, F0 & temp – time ensure sterilization. Supports program selection, traceability, multiple safety protections. Applicable for fabric, equipment, liquid sterilization.
Description
Features
● Horizontal circular inner chamber + jacket structure,safety, heat preservation, and drying function;
● Disc type embedded gear + Electric lock door structure,safety and reliable;
● Door seals are pneumatic;
● Equipped with standard equipment verification interface
● Pipeline system for the optimal design,SUS304 pipeline, clamp structure, quick assembly
● Control system:HMI man-machine interface, touch screen +microcomputer;
● F0 value and temperature time double guarantee sterilization effect, with perfect sterilization records;
● With program selection, parameter setting, equipment operation, report processing and traceability functions;
● Multiple safety protection(over-temperature,over-pressure protect)
● Sterilization process: fabric, equipment, liquid, BD,pressure testing, custom defined multiple procedures
Technical parameter
| Design pressure | -0.1~0.3Mpa | Design temperature | 150℃ |
| Working pressure | 0.23Mpa | Working Temperature | 105~138℃ |
| Vacuum | -0.086Mpa | Temperature Equilibrium | <+2.0℃ |
| Water Pressure | 0.1~0.2Mpa | Compressed air pressure | 0.4~0.7Mpa |
| External Steam Pressure | 0.3~0.7Mpa | Power voltage | Three-phase five-wire 380V 50Hz |
Model&Parameter (Without Pulse Vacuum )
| Overall Dimensions | Outer dimension(LxWxH)(mm) | Chamber Siz(ΦxL)(mm) | Steam Consumptior(kg) | Water Consumpion(kg) | Power(kw) | Net weight(kg) |
| WY-150D | 1260x690x1700 | Φ472×850 | ≤12 | ≤30 | ≤2+⑮ | 400/450 |
| WY-150S | 1130x690x1700 | Φ472×950 | ≤12 | ≤30 | ≤2+1 ⑮ | 400/450 |
| WY-200D | 1490x690x1700 | Φ472×1080 | ≤13 | ≤30 | ≤2+1 ⑮ | 450/500 |
| WY-200S | 1360x690x1700 | Φ472×1180 | ≤13 | ≤30 | ≤2+1 ⑮ | 450/500 |
| WY-300D | 1400x850x1730 | Φ620×960 | ≤18 | ≤40 | ≤2+1 ⑱ | 510/570 |
| WY-300S | 1150x850x1730 | Φ620×960 | ≤18 | ≤40 | ≤2+ 1 | 510/570 |
| WY-400D | 1680x850x1730 | Φ620×1230 | ≤22 | ≤40 | ≤2+1 ⑱ | 650/710 |
| WY-400S | 1500x850x1730 | Φ620×1310 | ≤22 | ≤40 | ≤2+ 1 | 650/710 |
Model&Parameter (With Pulse Vacuum )
| Model | Outer dimension(LxWxH)mm | Chamber Siz(ΦxL)mm | Steam Consumptior(kg) | Water Consumpion(kg) | Power(kw) | Net Weight Single/Double (kg) N |
| WY-100DM | 1090x640x1160 | Φ420×700 | ≤11 | ≤190 | ≤2+⑫ | 410 |
| WY-150DM | 1260x690x1700 | Φ472×850 | ≤13 | ≤190 | ≤2+⑮5 | 450/500 |
| WY-150SM | 1130x690x1700 | Φ472×950 | ≤13 | ≤190 | ≤2+⑮5 | 450/500 |
| WY-200DM | 1490x690x1700 | Φ472×1080 | ≤15 | ≤190 | ≤2+1 ⑮ | 500/550 |
| WY-200SM | 1360x690x1700 | Φ472×1180 | ≤15 | ≤190 | ≤2+⑮5 | 500/550 |
| WY-300DM | 1400x850x1730 | Φ620×960 | ≤20 | ≤200 | ≤2+1 ⑱ | 560/620 |
| WY-300SM | 1150x850x1730 | Φ620×960 | ≤20 | ≤200 | ≤2+ ⑱ | 560/620 |
| WY-400DM | 1680x850x1730 | Φ620×1230 | ≤25 | ≤200 | ≤2+ 1 | 700/760 |
| WY-400SM | 1500x850x1730 | Φ620×1310 | ≤25 | ≤200 | ≤2+ 1 | 700/760 |
