Automatic Digital Display Vertical Steam Sterilizer DGL-B series
-
Equipped with hand wheel quick-opening structure, microcomputer automatic control, and safety interlocks. Features digital display, touch buttons, and multiple protections (over-temperature, over-pressure, low water level, etc.) for reliable operation.
-
Available in 35L-100L volumes (DGL-35B to DGL-100B). Operates at 0.22Mpa/134℃, with adjustable sterilization temp (116-134℃) and time (4-120min). Made of high-quality stainless steel.
-
Automatic cold air discharge, steam exhaust, and buzzer reminder post-sterilization. Includes stainless steel bucket/basket; optional automatic water filling for added ease.
Description
●Hand wheel translation and quick opening structure.
● High quality stainless steel material.
● Microcomputer automatic control, arbitrary setting sterilization parameters.
● Safety interlocking device
● Digital display and Touch buttons.
● Standard test interface.
● Self-expanding seal.
● With automatic protection function:over temperature protection; over pressureself discharge protection; low water level protection; anti dry burning.
● With stainless steel bucket or basket.
● Buzzer reminder after sterilization, automatic stop.
● Automatic discharge of cold air,automatic steam exhaust after sterilization.
● Optional automatic water.
Technical parameter
Technical parameter | DGL-35B | DGL-50B | DGL-75B | DGL-100B |
Volume | 35L | 50L | 75L | 100L |
Power | 3.5kW | 3.5kW | 4.5kW | 4.5kW |
Voltage | AC 220V、50HZ | |||
Rated working pressure | 0.22Mpa | |||
Rated working temperature | 134℃ | |||
Sterilization temperature setting range | 116℃~134℃ | |||
Sterilization time setting range | 4~120 min | |||
Chamber volume(mm) | Ø 350×400 | Ø 350×525 | Ø 400×625 | Ø 450×650 |
Bucket dimension(mm) | Ø 330×320 | Ø 330×480 | Ø 380×540 | Ø 430×550 |
Basket dimension(mm) | Ø 320×350 | Ø320x240x2 | Ø 360x280x2 | Ø 410x300x2 |
Outer dimension(mm) | 480x480x1020 | 480x480x1050 | 525x525x1200 | 555x555x1250 |
Packing size(Lx WxH)(mm) | 580x630x1130 | 580x630x1230 | 630x680x1290 | 690x650x1410 |
Gross/net weight | 79/58KG | 106/80KG | 120/90KG | 133/106KG |
