Auto chart Projector WZ 2000AH
-
Advanced LCD vision tester for precise checks. Clear targets support diagnosis, correction, screening. Used in hospitals, optometry centers, schools, etc.
-
High – res LCD, sharp & high – contrast targets. Reduces errors, ensures accuracy. Flexible screen modes, diverse test graphs (E – charts, color – blindness tests).
-
AC100 – 240V, 80VA, 23″ 16:9 screen. 1M – 6M distance, decimal/imperial records. 8m remote, 6.8kg (590x465x160mm).
Description
This liquid crystal visual acuity chart is a vision testing device adopting advanced liquid crystal display technology, designed for precise measurement of human visual acuity.
With clear and standardized display of visual targets, it provides reliable evidence for ophthalmic diagnosis, vision correction, physical examination screening, etc.
It is suitable for various places such as ophthalmic hospitals, optometry centers, schools, and physical examination institutions. Equipped with a high-resolution LCD screen, the visual targets are sharp and clear with high contrast, which can effectively reduce visual errors and ensure the accuracy of vision test results. This product comes with a 1 – year quality guarantee.
| FEATURES | Details |
|---|---|
| Power | AC100 – 240V/50Hz/60Hz |
| Standard Power | 80VA |
| Distance（Dot pitch） | 0.284mm |
| Screen Ratio | 16:9 |
| Screen Size | 23″ |
| Visual Angel | H:170/M:160 |
| Color | 16.7M |
| Maximum Brightness | 300cd/m² |
| Working Distance | 1M~6M |
| Record Method | Decimal, imperial fraction recording method |
| Distance Of Control | Maximum remote distance not less than 8m |
| Screen | Horizontal / Vertical / Single character |
| Test Graph | E – chart / C – chart / Letter chart Children’s vision chart / Red – green color blindness test chart / WCTH four – point target Digital vision chart / Test Graph cross target / Contrast sensitivity test chart Red – green target / Honeycomb target / Maddox rod target / Astigmatic disc target, etc. |
| Weight | 6.8kg |
| Dimensions | 590(L)x465(W)x160(H)mm |
